Hatz Pump Solutions

State-of-the-art and robust drive technology

Maximum uptime & protection for pump applications. 1,000-hour service interval standard. Special warranty terms: 1 year, unlimited hours.

Technical Specifications

Hatz 4H50TIC - Pump (complete power unit)

EPA Tier IV final
Hp/kW@2100rpm: 60hp/45.5kW
Ft/lbs@1600rpm: 177ft/lbs
Nm@1600rpm: 240Nm

Including:

9.5qt. “long run oil sump”
Long run oil filter and cooler
Belt protection guards

Performance tracking module included = IoT ready!

Features

SAE #4 Housing
10” Flywheel
Pusher Fan
Belt Guards
Mounted Air Cleaner
Exhaust Pipe
Deep Oil Sump
IoT Included

Available Accessories

Coolant Drain
Oil Drain
Filter Kit
Control Panel
Up to 15ft Harness

Are You Interested in Hatz Technologies?

Get in Touch With Us.

Hatz - Specialist for Industrial Engines

Hatz is a globally active independent specialist for 1 to 4-cylinder engines. Our diesel engines are used in all application areas, such as construction machinery, compressors, commercial vehicles, agricultural machines, generators, conveyance vehicles, and ships. Hatz develops and manufactures diesel engines in a power range of 1.5 to 64 kW.
